UTV Roll Cage Sizes: OEM Tubing Diameter & Clamp Chart (2026)

Updated October 2026.

If you are trying to figure out what size your UTV roll cage is, the number you need is the outside diameter (OD) of the exact tube where the accessory will mount. Common factory UTV cage sizes include 1.75", 1.85", 1.875", and 2.0", but many machines use more than one tube diameter on the same cage.

This guide covers common OEM roll cage and roll bar sizes for Polaris, Can-Am, Yamaha, Kawasaki, Honda, Arctic Cat, and SPEED UTV models, plus how to measure your own cage before ordering mirrors, radio mounts, whip mounts, harness hardware, cameras, lights, and other clamp-on accessories.

UTV Roll Cage Size Quick Chart

Important: this chart is a starting point, not a substitute for measuring. Aftermarket cages, model-year changes, different bars on the same cage, and even thick coatings can affect clamp fitment.

How to Measure a UTV Roll Cage Tube

The correct measurement is the outside diameter of the tube where your accessory will actually clamp. Do not measure the inside diameter, and do not assume the A-pillar, roof crossbar, harness bar, and rear cage tubes are all the same size.

Method 1: Use a Digital Caliper

1. Place the caliper jaws across the outside of the tube.
2. Measure through the center of the tube.
3. Compare the reading with common UTV clamp sizes such as 1.625", 1.75", 1.85", 1.875", or 2.0".

Method 2: Use a Flexible Tape or String

If you do not have calipers, wrap a flexible tape measure or string around the tube to get the circumference, then divide by 3.14:

Tube diameter = circumference ÷ 3.14

• About 5.50" circumference = approximately 1.75" tube
• About 5.81" circumference = approximately 1.85" tube
• About 5.89" circumference = approximately 1.875" tube
• About 6.28" circumference = approximately 2.0" tube

Measure the exact bar where the accessory will mount. A cage can use several diameters, which is especially important when choosing UTV mirror clamps, camera mounts, lights, radio mounts, and whip mounts.

Polaris RZR Roll Cage Sizes

Polaris uses both round cages and profile-style cages, so identifying the platform matters just as much as measuring the tube.

Polaris General and newer Ranger models use profile-style cages rather than a normal round perimeter tube. Profile-specific clamps are required in many locations. The top/rear crossbars can still be round on some models, so measure where you plan to mount the part.

The Polaris Xpedition also uses a profile-style cage. Flat-surface mounting solutions may be needed and can require drilling rather than a conventional round clamp.

Shopping for RZR accessories? Browse Polaris RZR Parts & Accessories.

Can-Am Roll Cage Sizes

For X3-specific shopping, see Can-Am Maverick X3 Parts & Accessories. For utility models, see Can-Am Defender Parts & Accessories.

Yamaha Roll Cage Sizes

• YXZ1000R: 1.75" perimeter, 1.50" top crossbars
• Wolverine / Wolverine X2 / X4: 2.0" perimeter, 1.50" top crossbars
• Wolverine RMAX 1000: 2.0" perimeter, 1.50" top crossbars
• Rhino: 1.75" perimeter, 1.50" top crossbars and steering column
• Viking / Viking VI: 2.0" main cage; measure the mounting location before ordering

Kawasaki Roll Cage Sizes

• 2026+ Teryx4 H2 / Teryx5 H2: 2.0" perimeter and top crossbars; 1.25" front-row harness bar; 1.25" square grab handle; 1.75" chassis/rear angled tubes
• 2020+ Teryx KRX: 1.75" perimeter, 1.50" top crossbars
• Teryx / Teryx S / Teryx4: 1.875" perimeter, approximately 1.70" top crossbars
• Mule: cage sizes vary significantly by model; measure before buying a clamp

KRX owners can shop Kawasaki KRX 1000 Parts & Accessories. New H2 owners can browse Kawasaki Teryx H2 Parts & Accessories.

Honda Roll Cage Sizes

• Honda Talon 1000X / 1000R: 2.0" main cage
• Honda Pioneer 1000: 1.75" main cage
• Honda Pioneer 500 / 700: 1.625" main cage
• Honda Big Red MUV700: 1.625" main cage

If you own a Talon, browse Honda Talon Parts & Accessories. Always measure the exact tube used for the mount, especially if the cage has been replaced or modified.

Arctic Cat and SPEED UTV Roll Cage Sizes

• Arctic Cat Wildcat XX: 1.75" perimeter
• Wildcat / Wildcat X / Wildcat 4: 1.75" perimeter
• Arctic Cat Prowler: fitment varies; flat-surface mounting may be required depending on model and cage
• SPEED UTV: 1.75" perimeter, 1.50" B-pillar, 1.25" intrusion bars

What About CFMOTO, Segway, and Aftermarket UTV Cages?

For platforms not listed above, including many CFMOTO and Segway models, the safest approach is to measure the exact mounting tube. The same applies to any aftermarket cage. Cage builders often use different tubing than the factory cage, and a used machine may have been modified by a previous owner.

Do not select a clamp purely from the UTV model name when the cage is aftermarket.

Round Cage vs. Profile Cage: Why It Matters

A conventional round cage uses clamps sized by tube outside diameter. A profile cage is shaped rather than round, so a standard 1.75" or 2.0" clamp will not fit correctly even if one dimension appears close.

Common profile-cage applications include many Polaris Ranger and General models, Can-Am Defender, Maverick Sport/Trail, and newer Commander models. These typically need profile-specific or flat-surface mounting hardware.

Once you have the outside diameter, compare mirrors, lights, radio mounts and whip mounts. Confirm the clamp's tube-size range, inserts and shape—not merely the vehicle brand.

Best Accessories to Shop After You Know Your Cage Size

• UTV Mirrors — one of the most common clamp-on cage accessories
• Rugged Radios UTV Mounts — radio and intercom mounting solutions
• Whip Mounts & Installation — clamp and mounting options for lighted whips
• Harnesses & Harness Accessories — verify harness-bar size and mounting style
• UTV Roofs — vehicle-specific roofs avoid cage-size guesswork
• Rugged Radios — complete communication systems and mounting accessories

UTV Roll Cage Size FAQ

What is the most common UTV roll cage size?

1.75" and 2.0" are two of the most common round cage sizes, but there are many exceptions. Can-Am Maverick X3 and Maverick R use 1.85" perimeter tubing, while several Kawasaki Teryx models use 1.875".

What size is a Polaris RZR roll cage?

It depends on the RZR platform. RZR Pro R, Pro S, Pro XP, and Turbo R use 2.0" perimeter tubing. Many RZR XP platforms use 1.75" perimeter tubing. Crossbars and harness bars can use smaller diameters.

What size is a Can-Am X3 roll cage?

The Can-Am Maverick X3 uses 1.85" perimeter tubing. The top front crossbar is commonly 1.50", and the rear harness bar is 2.50".

What size is a Honda Talon roll cage?

The Honda Talon uses a 2.0" main/perimeter cage.

What size is a Kawasaki KRX roll cage?

The Kawasaki Teryx KRX uses a 1.75" main cage with 1.50" top crossbars.

What size is a Yamaha Wolverine or RMAX roll cage?

Yamaha Wolverine and Wolverine RMAX models use a 2.0" main cage with 1.50" top crossbars.

How do I measure a roll cage without calipers?

Measure the tube circumference with flexible tape or string, then divide by 3.14. For example, about 5.50" around is roughly a 1.75" tube, while 6.28" around is a 2.0" tube.

Does powder coat change roll cage clamp size?

A normal coating usually does not change the nominal tube size you should order, but a heavy coating, wrap, or bedliner can affect clamp fit. Measure the finished tube if you are uncertain.

Do aftermarket UTV cages use the same tubing as OEM cages?

Not necessarily. Aftermarket cage builders choose their own tubing sizes and designs, so measure an aftermarket cage instead of relying on the factory chart.

Bottom Line

Use the OEM chart to narrow down your likely cage size, then measure the exact mounting location before ordering. That simple step prevents the most common fitment mistake with UTV mirrors, radio mounts, whip mounts, cameras, lights, and other cage-mounted accessories.

The OEM sizing information in this guide was cross-checked against the current Axia Alloys OEM roll cage fitment guide, a widely used reference for cage-mounted accessory fitment.
